6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

Brand Name : BH

Model Number : BH367F

Certification : CE

Place of Origin : Qingdao ,China

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Supply Ability : 3000sets /year

Delivery Time : 8-20Days

Packaging Details : 3000*750*1500mm

Product Name : Edge banding machine

Working voltage : 380V/50Hz

Total power : 7kw

Plate thickness : 10~60mm

Conveyor speed : 18~24m/min

Minimum width of board : 50mm

Contact Now

We produce alarge numher of products everyday, fast deliver
Support any custom color, LOGO, engine, airconditioning and other confguration
1piece can also he customized

6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

BHM START 300 High-speed fully automatic edge banding machine

Description:

The New BHM START 300 automatic edge banding machine is suitable for board shops and small processing factories, with vertical display control panels. Hand-cranked digital display adjustment pressure beam height.


The use of large-capacity glue pot can be continuously sealed with continuous edge sealing. Just enter the straight plate, pass gluing, pressing, rough trimming, end trimming, corner trimming, large diameter vacuuming, secondary scraping and buffing. The plate is molded at one time.


Specifications:

Outline dimension 3500*750*1500mm Conveyor speed 18~24m/min
Machine weigh 1000KG Minimum width of boar 50mm
Working voltag 380V/50Hz Minimum length of boar 70mm
Total power 7KW Woking pressure 0.7Mpa
Plate thickness 10-60mm Edge banding thickness 0.3~3mm


For consumers : Our Woodworking machineryare affordable, customizable, and come in a dvariety of models. Whether it is small or large woodworking machinery, they can perfectly meet your needs. Supplier : Our Woodworking machineryare has redefined industry standards with innovative features, durability, We will provide you with sufficient profit margins and after-sales service for our products within 1-3 years. Some parts can be shipped by air, express delivery is faster, and we will provide you with testing before delivery to ensure product quality. We will assist you with all testing and promote it for free on your country and website, and support customization! As a leading Woodworking machineryare manufacturer, We understand the doubts and problems that customers have when purchasing woodworking machinery,That's why we have tailored our products to alleviate these concerns and provide unparalleled value.

6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

Applications:

1. Encoder Control all actions of the whole machine, with sensitive response and low failure rate.


2.Intelligent control The standard plc microcomputer control adopts the principle of time control, greatly improving stability and safety.


3.Glue can The glue coating device heats hot melt adhesive through a glue tank and uses a suction structure to evenly apply glue, ensuring strong adhesion.


4.End cutting The edges of the wooden board are cut using single guide rails at both ends of the chessboard.


5.Fine trimming High speed oblique cutting motor,adjustable operation is more convenient,and the alloy disc ensures smooth and even trimming.


6.Buffing Polishing makes the edge sealing section smoother and more effective.

6 Functions Compact 380V Automatic Edge Banding Machine for Woodworking

FAQ


Q1:Can customized services be supported?

A1:Yes, we can customize the color, size and logo you need


Q2:Where is your factory located?

A2:We are a chinese manufacturer in qingdao city, shandong province


Q3:Can you make the machine according to my design or prototype?

A3:Yes. We have an professional designer for working out the most suitable Design and production plan for the machine that you are going to book with us


Q4: This is the first time I use this kind of machine, is it easy operate?

A4: There are guide video that show how to use machine and english instruction book send to you with machine. If there is still have any question, we will provide free professinal guide for you until you could use machine well.


Q5:What’s your MOQ and delivery?

A5:Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.


Q6: How is your after sales service?

A6: Our sales are online for 24-hours. We can also supply overseas install service.


Q7: If my machine is broken. Can you repair it for me?

A7: Yes. We have free training online.


If there is big trouble with your machine in the warranty time, we can repair it.
